Junghans J15, updated 30.12.2022

Junghans
Kind:
Production:
Production site:
Type:
Variants:
Catalog Group:
Size:
Outer Diameter:
Nominal Diameter:
Height:
f:
Power reserve:
Balance staff:
Stem:



Mainspring:


Liftangle:
Jewels:
Hour hand:
Minute hand:
Seond hand:
Distance Center to Fourth wheel:
Dial feet position:



Movement weight:
Reference picture:
Master watch
1914 - 1925
Schramberg
Hunter case
J15
106
19'''
43,6 mm
43,0 mm
5,0 mm
18000 A/h
34 h
U409
W298
Junghans mentions 3 different stems
with 23,75 mm, 25,4 mm
and 26,4 mm length
Zf3495, 460 x 16,0  x 2 x 0,20 mm
Junghans mentions spring
number 1002 465 x 2,0 x 0,20 mm.
38°
15
Ø 1,85 x 20 mm
Ø 1,15 x 14 mm
Ø 0,21 x 7 mm
11,7 mm
CW 33,9 mm
FW 22,5 mm
CW 30,7 mm
FW 49,0 mm
47,1 g
F.W.S 1942 page 18
Older type set spring.
-
Older type click spring and set spring assembly.
-
The later used click spring and set spring assembly.
-
This is the newer type set spring.
-
Below a new click spring like later in the J47. Should be around 1921.  Also seen on the J13. Picture courtesy of Otto B.
J15
-
J15 Dial Feet Position
